Model Number
AUD-09HX4SVNL
AUD-12HX4SVNL
AUD-18HX4SSNL1
AUD-24HX4SFLH1
AUD-36HX4SDHH2
Indoor model
AUD-09HX4SNL
AUD-12HX4SNL
AUD-18HX4SNL1
AUD-24HX4SLH1
AUD-36HX4SDHH2
Outdoor model
AUW-09H4SV
AUW-12H4SV
AUW-18H4SS
AUW-24H4SF
AUW-36H4SD
Power supply (Indoor)
V-ph-Hz
220~240-1-50
220~240-1-50
220~240-1-50
220~240-1-50
220~240-1-50
Power supply (Outdoor)
V-ph-Hz
220~240-1-50
220~240-1-50
220~240-1-50
220~240-1-50
220~240-1-50
Cooling
Capacity
W
3000
3516
5000
7050
9850
Input
W
1080
1116
1720
2340
3070
Current
A
5.1
5.1
7.5
10.2
14.8
Heating
Capacity
W
3100
3692
5700
8000
10000
Input
W
1065
1022
1670
2215
2770
Current
A
4.8
4.8
7.3
9.6
13.8
Indoor air flow Rated (Hi/Med/Lo)
m3/h
650/470/450
650/470/450
750/670/630
1250/1000/900
1800/1650/1500
Indoor air flow Rated (CFM)
CFM
382/276/265
382/276/265
441/394/371
735/588/529
1059/971/882
ESP
Rated
Pa
10
10
10
50
50
Range
Pa
10/30
10/30
10/30
50/80
50/80
Indoor noise level (Hi/Med/Lo)
dB(A)
34/29/28
34/31/29
38/36/35
42/40/38
40/38/37
Indoor Unit
Dimension (WxHxD)
mm
900x190x447
900x190x447
900x190x447
900x270x720
1300x350x800
Packing (WxHxD)
mm
1070x236x580
1070x236x580
1070x236x580
1170x340x870
1550x410x940
Net/Gross weight
kg
19/25
19/25
19/25
30/35
54/62
Design Pressure (H/L)
MPa
4.15/1.6
4.15/1.6
4.8/1.6
4.8/1.6
4.4/1.6
Drainage water pipe diameter
mm
dΦ32
dΦ32
dΦ32
dΦ32
dΦ32
Refrigerant piping
Liquid side / Gas side
mm
Φ6.35/Φ12.7(1/4"/1/2")
Φ6.35/Φ12.7(1/4"/1/2")
Φ6.35/Φ12.7(1/4"/1/2")
Φ9.52/Φ15.88(3/8"/5/8")
Φ9.52/Φ19(3/8"/3/4")
Outdoor noise level (sound pressure)
dB(A)
55
55
54
56
62
Outdoor Unit
Dimension (WxHxD)
mm
715x482x240
715x482x240
810x280x585
860x665x310
885x795x366
Packing (WxHxD)
mm
830x530x315
830x530x315
940x420x640
990x730x450
1050x890x500
Net/Gross weight
kg
28/30
28/30
42/45
51/56
65/69
Refrigerant type / Quantity
Type
R410A
R410A
R410A
R410A
R410A
Charged volume
kg
0.85
0.85
1.30
1.58
2.15
Design Pressure (H/L)
MPa
4.15/1.6
4.15/1.6
4.8/1.6
4.8/1.6
4.4/1.6
Refrigerant piping
Liquid side / Gas side
mm
Φ6.35/Φ12.7(1/4"/1/2")
Φ6.35/Φ12.7(1/4"/1/2")
Φ6.35/Φ12.7(1/4"/1/2")
Φ9.52/Φ15.88(3/8"/5/8")
Φ9.52/Φ19(3/8"/3/4")
Max pipe length
m
15
15
20
30
30
Max difference in level
m
7.5
7.5
15
15
20
Ambient temperature
Cooling
°C
-15~43
-15~43
-15~43
-15~43
-15~43
Heating
°C
-10~24
-10~24
-10~24
-10~24
-10~24
Qty'per 20'/40'/40'HQ
Indoor+Outdoor
100/218/243
100/218/243
66/135/174
40/80/88
21/44/52
Model Number
AUD-36HX6SDHH1
AUD-48HX6SEHH1
AUD-60HX6SPHH1
Indoor model
AUD-36HX4SHH1
AUD-48HX4SHH
AUD-60HX4SHH
Outdoor model
AUW-36H6SD
AUW-48H6SE1
AUW-60H6SP1
Power supply (Indoor)
V-ph-Hz
220~240-1-50
220~240-1-50
220~240-1-50
Power supply (Outdoor)
V-ph-Hz
380-415-3-50
380-415-3-50
380-415-3-50
Cooling
Capacity
W
10550
14000
16000
Input
W
3505
4651
5694
Current
A
6.9
8.8
10.0
Heating
Capacity
W
11250
15000
17500
Input
W
3100
4532
5814
Current
A
6.4
8.6
10.3
Indoor air flow Rated (Hi/Med/Lo)
m3/h
1800/1650/1500
2000/1800/1600
2000/1800/1600
Indoor air flow Rated (CFM)
CFM
1059/971/882
1176/1058/941
1176/1058/941
ESP
Rated
Pa
50
80
80
Range
Pa
50/80
80/120
80/120
Indoor noise level (Hi/Med/Lo)
dB(A)
40/38/37
46/44/42
46/44/42
Indoor Unit
Dimension (WxHxD)
mm
1300x350x800
1300x350x800
1300x350x800
Packing (WxHxD)
mm
1550x410x940
1550x410x940
1550x410x940
Net/Gross weight
kg
54/62
54/62
54/62
Design Pressure (H/L)
MPa
4.8/1.6
4.15/1.5
4.15/1.5
Drainage water pipe diameter
mm
dΦ32
dΦ32
dΦ32
Refrigerant piping
Liquid side / Gas side
mm
Φ9.52/Φ19(3/8"/3/4")
Φ9.52/Φ19(3/8"/3/4")
Φ9.52/Φ19(3/8"/3/4")
Outdoor noise level (sound pressure)
dB(A)
62
55
58
Outdoor Unit
Dimension (WxHxD)
mm
885×795×366
950x1050x340
950x1386x340
Packing (WxHxD)
mm
1050×890×500
1110x1200x460
1110x1530x460
Net/Gross weight
kg
67/71
96/103
106/116
Refrigerant type / Quantity
Type
R410A
R410A
R410A
Charged volume
kg
2.60
2.40
3.10
Design Pressure (H/L)
MPa
4.8/1.6
4.15/1.5
4.15/1.5
Refrigerant piping
Liquid side / Gas side
mm
Φ9.52/Φ19(3/8"/3/4")
Φ9.52/Φ19.05(3/8"/3/4")
Φ9.52/Φ19.05(3/8"/3/4")
Max pipe length
m
30
50
50
Max difference in level
m
20
30
30
Ambient temperature
Cooling
°C
-15~43
-15~43
-15~43
Heating
°C
-10~24
-10~24
-10~24
Qty'per 20'/40'/40'HQ
Indoor+Outdoor
21/44/52
19/38/48
19/38/40
